How-to: Create an ETL Job using AWS Glue Studio, S3, & Athena
--
Background
In this blog post, I will walk us through on how to create an ETL job using the following AWS Cloud Services:
- Amazon S3 (for intermediary data storage)
- AWS Glue Studio (main engine of the ETL job)
- Amazon Athena (query tool)
ETL stands for Extract, Transform, and Load.
In almost all Enterprise IT settings, it is very common to have huge volumes of Analytical data. In order for that data to be consumable and used by business areas to generate insights and forecast business goals, the data needs to be:
- Extracted from where it is stored/originated,
- Transformed to fit a certain format (usually involves cleaning the data, removing duplicates, etc.)
and then,
3. Loaded into the target destination source.
Very often, there is also the presence of a large data warehouse, and multiple databases/storage layers feeding data into the larger warehouse for general business consumption.
Without further ado, we will now create an ETL Job using AWS Glue (an event-driven, serverless computing service).
Step 1 — Create an S3 Bucket
This S3 Bucket will store our data. We’re basically just building a database within the S3 Object storage service.
Step 2 — Create some Mock Data
For this step, I just created a quick .csv file with data about coffee orders.
This data file will be uploaded to the etl-tutorial-bucket from the previous step.
Step 3 — Upload the coffee data file to the S3 Bucket
Step 4 — Create this IAM Role for Glue with the Required permissions
Step 5— Define the Glue Data Crawler in AWS Glue
AWS Glue was launched in 2017. It is a fully-managed, serverless, and AWS Cloud-optimized ETL Service offering.
Using Glue, there are numerous ways we can connect to our data store in S3. However, for this tutorial, I am going to demo this using Glue Crawler.
Glue Crawler is one of the most widely-used method among Data Engineers.
Basically, this Crawler will “crawl” the data file in our S3 bucket, and using the data available in the file in S3 will create a table schema in Glue.
To create and add the Crawler to our S3 data store:
5a. Gave my crawler the name etl-tutorial-crawler
then click Next.
5b. You can keep the default settings as is for the Crawler. Click Next.
5c. Select S3 for the data store, and add the name of your S3 bucket. The click Next.
5d. Select the Choose an existing IAM Role radio button, and select the IAM Role we created in Step 4. Then click Next.
5e. Set the frequency to Run on Demand. Then click Next. (Note: if required, you can always set customized scheduling for your Crawler to run on an hourly, daily, weekly, o monthly cadence).
5f. For storing the output from the Crawler, I created a database coffee-database
and then clicked Next.
5g. Lastly, review all the settings that we’ve configured and click Finish to create our Crawler.
5h. Once the Crawler has been created, we should see this:
Try running the Crawler. If the job status updates from starting to stopping, and then to ready, that tells that the Crawler job was successful.
Step 6 — Defining our Glue Job
Now that we have finished setting up the Glue Crawler to point and recognize the data file in S3, we will define our Glue job to perform the ETL portion of this tutorial.
6a. From the AWS Console, go to AWS Glue Studio:
You will want to select Amazon S3 as both the Source and Target. Click Create.
Set up your Glue Job to look like this:
6b. Run the job.
While it’s running, you should see an output like this:
After the Glue job is finished running, your output should look like this:
Step 7 — Querying our data using Athena
AWS Athena is a query service offered by AWS that analyzes data in S3 using SQL. For this tutorial, I will run Athena to query the ETL data and run some SQL operations.
Go to the AWS console, and search for Athena. Then run this query as shown below:
After running the query, we should see our results. :)
Overall summary
When it comes to data engineering, in general, ETL operations and pipelines are a huge part of it. Apart from Glue, there are a multitude of other ETL services (i.e. Cloud Air Fusion by Google Cloud, Data Factory offerred by Azure, and many others).
Aside from whichever one you pick, the basic idea is that it should assist with reduction of engineering efforts required by supplying a base (source and target locations and configurations).
We have just completed ETL using AWS Glue. :)
My hope is that this walkthrough helps you with your projects!
In case I missed anything, or if you have any questions/thoughts, please submit them in the comments section below.
